Adetɔnbea Gyinapɛn-Compact, Smart, Shelf-Asiesie
Shelf-Edge Wɔayɛ no Yie
4.2-inch form factor no yɛ wiase nyinaa adetɔn gyinapɛn-atirimpɔw-a wɔasi sɛ ɛbɛkɔ slot tẽẽ akɔ shelf keteke nhyehyɛe ne label holders a ɛwɔ hɔ dedaw mu a nsakrae biara nni mu, a ɛma wotumi de sotɔɔ mũ no nyinaa di dwuma wɔ nnɔnhwerew mu, ɛnyɛ nna mu.
High-Density a Wɔde Kata So
Compact 97.4×88.9 mm footprint ma kwan ma tags pii wɔ shelf run biara mu. Fa di dwuma wɔ SKU biara so-fi akwan teateaa-kwan so aduantɔnbea so kosi sotɔɔ ahorow a ɛyɛ mmerɛw a wɔahyɛ no ma denneennen-a womfa akenkan mmɔ afɔre.
Cloud-Boɔ a Wɔahwɛ So
Real-bere mununkum nhyiamu ma intanɛt ne in-store boɔ yɛ pɛpɛɛpɛ. Automate batch updates wɔ tag mpempem pii so dɔnhwerew biara-yi nsaano mfomsoɔ ne boɔ a ɛnhyia fi hɔ ntɛm ara.
Drop-wɔ nhyehyɛɛ mu ma standard shelf rails, peg hooks, label holders, ne magnetic mounts-nnwinnade anaa shelf nsakrae biara nhia.
Nea enti a 4.2" ne Wiase Nyinaa ESL Kɛse a Wɔde Di Dwuma Sen Biara
Ɛsõ sɛnea ɛbɛyɛ a ɛbɛda nneɛma bo, barcodes, ne nsɛm a wɔde hyɛ nkurɔfo nkuran adi pefee wɔ 400×300 nsusuwii mu, nanso ɛyɛ ketewaa sɛnea ɛbɛyɛ a ɛbɛfata standard shelf strips a wɔde di dwuma wɔ 90% a wɔtɔn nneɛma wɔ wiase nyinaa.
Form factor ketewa kyerɛ sɛ ɛka a ɛba fam wɔ -unit biara ho. Sɛ wɔde 5+ afe battery nkwa ne krataa a wɔde di dwuma zero ka ho a, adetɔnfo dodow no ara hu ROI a edi mũ wɔ asram 12–18 mu.
Wɔ 94 g pɛ mu no, tag no twetwe kɔ label holder biara mu anaasɛ ɛforo magnetically a ɛnkari shelf anoano-adwumayɛfo betumi de 500+ units ahyɛ mu wɔ shift biako mu.
NFC tap nkitahodi, 7-kɔla pick-to-kanea LED, multi-kratafa nkyerɛkyerɛmu nsakrae, ne QR koodu nkabom-biribiara a ɛwɔ mfonini akɛse a wɔaboaboa ano wɔ shelf-edge form factor mu.
Boɔ a ɛyɛ den ne nhyehyɛɛ a ɛyɛ ketewa ma ɛyɛ yie sɛ wode shelf tag biara a ɛwɔ wo sotɔɔ mu no bɛhyɛ digyital mu-ɛnyɛ nneɛma a ne boɔ yɛ den-nneɛma a ɛsom boɔ nko ara-ma dijitaal akatasoɔ 100% ne boɔ a ɛyɛ pɛpɛɛpɛ.
Wɔasi no sɛnea ɛbɛyɛ a ɛbɛyɛ adwuma na atumi atra hɔ akyɛ
Crisp E-Ink Akenkan a Wɔde Yɛ Adwuma
4.2-inch E-ink display a ɛwɔ 400×300 pixel nsusuwii ne 84.8×63.6 mm active window. Black/White/Red kɔla mmoa hwɛ hu sɛ nneɛma bo ne nsɛm a wɔde hyɛ nkurɔfo nkuran no yɛ razor-sharp wɔ sotɔɔ kanea biara ase-a akenkan osuahu a ɛte sɛ krataa fi bɛyɛ 180℃.
Wɔakyekye-Wɔ NFC Nkitahodi mu
Adetɔfo bɔ wɔn fon so na woanya nneɛma no ho nsɛm, aduannuru ho nsɛm, intanɛt so nsɛm a wɔasusuw ho, anaasɛ coupon ahorow a ɛyɛ soronko. Adwumayɛfoɔ de NFC-enabled PDAs di dwuma ma ntɛm ara tag auditing, binding, ne boɔ a wɔdi ho adanseɛ wɔ shelf ano.
Ultra-Tumi a ɛba fam, Nkwa tenten
CR2450 batere abiɛsa a wotumi sesa no de mfe 5+ adwumayɛ ma wɔ 3–5 updates da biara. E-ink di tumi zero bere a static-wo tags kɔ so da adi mpo bere a battery no asa, hwɛ hu sɛ bo a wɔbɔ no nkɔ da.
Tough Enough ma Akwantuo Biara
IPX5/IPX7 mfutuma ne nsuo a ɛko tia, ɛyɛ adwuma wɔ ahotosoɔ mu wɔ 0℃–40℃mmeaeɛ. Freezer-grade options a ɛwɔ hɔ kɔsi -25℃ma frigye ne fresh produce afã horow.
7-Kɔla Paw-kɔ-Han LED
LED a wɔaka abom boa kɔkɔɔ, ahabammono, bruu, kɔkɔɔ, cyan, kɔkɔɔ, ne fitaa a ɛwɔ flash nsusuwii a wotumi sesa. Ɛyɛ papa ma order picking, restocking akwankyerɛ, promotion highlighting, ne multi-adwuma nsonsonoe wɔ retail ne warehouse nhyehyɛe mu.
Wireless Nkitahodi a Wotumi De Ho To So
2.4 GHz frequency hopping protocol a BLE 5.0 ka ho no de interference resistance a emu yɛ den ne 30–50 m kwan ma wɔ dense retail environments mu. Frequency hopping kwati Wi-Fi congestion ma 99%+ update nkonimdie dodoɔ-mpo wɔ nnɔnhwereɛ a nnipa pii wɔ mu.
Smart Features wɔ Nipadua a Ɛyɛ Compact mu
7-Kɔla LED Pick-kɔ-Han
Order Picking & Restocking a Wɔbɛsan Ahyehyɛ
Aisle Navigation & Ɔkwan a Wɔhwehwɛ
Flash Alerts a Wɔde Ma Nkɔso
Kɔla-Coded Adwuma Nsonsonoe
NFC Tap Nkitahodi
Fa gu Cart mu Ntɛm ara
Nya Product Specs & Nhwehwɛmu
Fa Nneɛma a Wɔde Ma a Wɔayɛ no Ankasa
Link a ɛkɔ Intanɛt so Adetɔnbea Nkratafa so
Multi-Nkratafa a Wɔde Kyerɛkyerɛ
Bo, Promo & Inventory Nkratafa
Nneɛma a Wɔde Yɛ & Aduandi Ho Nokwasɛm
Mfiase & Adansedi Ho Nsɛm
Sesa denam Button anaa Cloud Command so
QR Kood a Wɔde Bɛka Abom
Fa Kar Kɔ Intanɛt So Adetɔnbea
Nokwaredi & Asɔremma Nkyerɛwde-Up
Product Guides & Sɛnea-Wɔde Video ahorow
Side-by-Afã Ntotoho
Nsɛm a Wɔakyerɛkyerɛ mu
|
Spec |
Nkyerɛmu |
|
Screen Kɛseɛ |
4.2-inch E-ink Ɛlektrɔnik Krataa a Wɔde Kyerɛkyerɛ |
|
Nhyehyɛeɛ |
400 x 300 piksel |
|
Beae a Wɔde Kyerɛkyerɛ a Ɛyɛ Nnam |
84.8 x 63.6 mm |
|
Kɔla ahorow a Wɔde Kyerɛkyerɛ |
Tuntum / Fitaa / Kɔkɔɔ |
|
Nsusuwii ahorow |
97.4 x 88.9 x 13.8 mm |
|
Muduro |
94 g |
|
Battery Nkwa Nkwa |
5+ mfe (3-5 da biara da nsɛm foforo, wobetumi asesa) |
|
Battery Type a Wɔde Di Dwuma |
3 x CR2450 na ɛwɔ hɔ |
|
Nkutahodie |
2.4 GHz Frequency Hopping na ɛyɛ adwuma |
|
Dodoɔ |
30-50 mita (ɛgyina nneɛma a atwa yɛn ho ahyia so) . |
|
Ɔhyew a Wɔde Yɛ Adwumayɛ |
0 digrii – 40 digrii (freezer-grade kosi -25 digrii wɔ hɔ) |
|
NFC na ɛwɔ hɔ |
Wɔboa (kenkan/kyerɛw) . |
|
DII KAN |
Kɔla ahorow 7 (Kɔkɔbɔ/Ahabammono/Blue/Kɔkɔɔ/Cyan/Purple/Fitaa) . |
|
Ahobammɔ Ho Nhwehwɛmu |
IPX5 / IPX7 na ɛwɔ hɔ |
Nnwuma a Nyansa wom ma Nnɛyi Adetɔnbea
Nneɛma Bo a Wɔyɛ no Ntɛm ara: Proprietary 2.4 GHz protocol hwɛ hu sɛ 99.99% nkonimdi rate ma wireless bo nsakrae-bua akansifo bo, bere-gyina promotions, anaasɛ dynamic markdowns wɔ sikani mu, ɛnyɛ nnɔnhwerew.
Twe-na-Twe Template Editor no gu: Fa nsɛm, mfonini, barcode, QR code, ne frankaa a wɔde hyɛ nkurɔfo nkuran yɛ nhyehyɛe ahorow a wɔahyɛ da ayɛ. Hwɛ nsakraeɛ wɔ bere ankasa mu na pia kɔ tag ankorankoro anaa sie-akuw a ɛtrɛw ntɛm ara.
Intanɛt so Nhwɛsode Guadibea: Kɔ nhomakorabea kɛse bi a ɛwɔ nsusuwso ahorow a wɔadi kan ayɛ a wɔayɛ ama aguadidan akɛse, nnurutɔnbea ahorow, ɛlɛtrɔnik nneɛma, ntadehyɛ, ne nea ɛkeka ho-twe na fa adwumayɛfo nhyehyɛe ahorow di dwuma wɔ simma kakraa bi mu.
Multi-Kratafa no mu Nsɛm a Wɔsesa: Pre-load nsɛm nkratafa pii (bo, nneɛma a wɔakora so, nkɔso, nneɛma a wɔde yɛ) na sesa denam honam fam bɔtn anaa akyirikyiri mununkum ahyɛde so-comact tag biako de afiri kaad a edi mũ no mu dɔ ma.
Smart Inventory Nneɛma a Wɔde Yɛ Adwuma: Auto-beae map, low-stock alerts, ne heat-map analytics boa adwuma so ahwɛfoɔ ma wɔyɛ shelf nhyehyeɛ yie ne restocking adwumayɛ nhyehyɛeɛ firi dashboard baako so.
Versatile Mounting ma Shelf Biara
4.2" tag no twetwe tẽẽ kɔ standard shelf label holders a wɔde di dwuma wɔ grocery, retail, ne warehouse shelving nyinaa mu wɔ wiase nyinaa-nnwinnade anaa nsakrae biara nhia.
Standard shelf-edge keteke / label kurafo a wɔde hyɛ mu
Peg hooks a wɔde sɛn aguade
Magnetic akyi a ɛyɛ den ma dade racking ne gondola
Freezer clips ne acrylic pon gyina hɔ ma mmeae a ɛyɛ foforo
Screw-asiesie anaa anti-korɔnbɔ mounts ma mmeae a ɛsom bo kɛse-
Legoyo 4.2" ESL-Ɛyɛ pɛpɛɛpɛ Ma:
FAQ
Asɛmmisa: Dɛn nti na wopaw ne kɛse a ne kɛse yɛ nsateakwaa 4.2 sen ESL tag akɛse?
A: 4.2-inch no yɛ wiase nyinaa adetɔn gyinapɛn ma shelf-edge bo. Ɛhyɛ label holders a ɛwɔ hɔ dada no mu tẽẽ a wɔnyɛ nsakraeɛ biara, ɛyɛ hare (94 g), ɛho ka sua wɔ unit biara mu, na ɛma wotumi de store coverage a edi mũ-{7}}bere a ɛda so ara de NFC, 7-color LED, ne multi-page smart features a wohu wɔ model akɛseɛ mu no ma.
Asɛmmisa: Batere no di bere tenten ahe?
A: CR2450 battery abiɛsa ma 5+ mfeɛ nkwa a 3–5 da biara da updates. Battery no yɛ nea wotumi sesa koraa, na nhyehyɛe no de nnam bɔ wo kɔkɔ bere a levels no so atew-sɛnea ɛbɛyɛ a wubetumi adi kan ayɛ nsiesie ho nhyehyɛe.
Asɛmmisa: So wotumi kenkan nea wɔde kyerɛ no wɔ kanea tebea nyinaa mu?
A: Yiw. E-ink mfiridwuma de ambient light reflection (te sɛ krataa ankasa) di dwuma sen sɛ wɔde akyi kanea bedi dwuma. 400×300 resolution a ɛwɔ 84.8×63.6 mm display area no de nsɛm a ɛyɛ crisp ne barcodes ma wɔ sotɔɔ kanea biara ase-a fluorescent fixtures a ɛhyerɛn ne mfɛnsere a ɛbɛn ka ho.
Asɛmmisa: Wotumi de ho to wireless nkitahodi so dɛn wɔ sotɔɔ ahorow a adagyew nnim mu?
A: 2.4G frequency hopping + BLE 5.0 kwati Wi-Fi ntwitwiridii a ɛwɔ 99%+ coverage-wɔ mpo wɔ mmeae a ɛyɛ density kɛse. Nneɛma a wɔde yɛ adwuma hia tumi ne intanɛt nkutoo; full store rollout taa gye nnafua 1-3.
Asɛmmisa: So metumi ayɛ label design no ama me brand no?
A: Akyinnye biara nni ho. Yɛn drag-ne-drop template editor no ma wo kwan ma wo hyehyɛ nhyehyeɛ a wode nsɛm a wɔahyɛ da ayɛ, ahyɛnsodeɛ, barcode, ne QR koodu. Wubetumi nso apaw afi yɛn intanɛt so nsusuwso gua so a nnwuma-nsusuwii pɔtee ɔhaha pii ayɛ krado sɛ wɔde bedi dwuma ntɛm ara.
Asɛmmisa: So eyinom bɛyɛ adwuma wɔ mmeae a awɔw wom anaasɛ ɛhɔ yɛ nsu?
A: Standard mfonini ahorow di 0 digrii –40 digrii ne IPX7 nsu a wɔde siw ano. Freezer-grade nkyerɛaseɛ no yɛ adwuma kɔsi -25℃ma frigye nkotokuo, deli counters, ne cold-chain adekoradan.
Asɛmmisa: Ɔkwan bɛn so na nkabom ne me POS/ERP yɛ adwuma?
A: Bue REST APIs ma kwan abien-kwan a ɛnyɛ den a ɛfa nneɛma bo, nneɛma a wɔakora so, ne nkɔso a ɛne wo POS, ERP, anaa e{1}}aguadi kwan a ɛwɔ hɔ dedaw-adwumayɛ mu nsakrae biara ho nhia.
Asɛmmisa: Bere bɛn na mɛhu ROI?
A: Adetɔfo dodow no ara san nya sika a wɔde asie wɔ asram 12–18 mu denam adwumayɛfo a wɔkora so, krataa a wɔmmɔ ho ka biara, ne adetɔn a ɛkɔ soro fi nsɛm a wɔde hyɛ nkurɔfo nkuran a eye ne bo a wɔbɔ no pɛpɛɛpɛ mu. 4.2-inch no ka a ɛba fam wɔ unit biara ho no ma payback yɛ ntɛmntɛm sɛ wɔde toto ESL akɛseɛ ho a.
